Features

A new platform for streamlining procurement takes shape.

Supply chain has been the story of the past year, and a new face to the industry proposes to help resolve that by connecting electronics engineers with printed circuit board assemblers.

Vincent Bedát is a mechanical engineer and recent MBA graduate of the MIT Sloan School of Management. He is also founder of a San Francisco-based startup called Volthub. I came across Volthub as part of an announcement of the finalists for the MIT $100K Entrepreneurship Competition. That program has various aspects to it, but in short it’s a way to match early-stage teams with industry experts and entrepreneurs, and perhaps gain some seed money along the way. Some of the companies that have been part of the competition over the years include HubSpot and Akamai Technologies.

Vincent Bedat
Vincent Bedát

Bedát hails from Zurich, Switzerland, where he also studied, graduating with a master’s in mechanical engineering from ETH Zurich. He then went on to work at the robotics startup Synapticon in Stuttgart, Germany, as a mechanical engineer and eventually project manager.

To continue reading, please log in or register using the link in the upper right corner of the page.

Read more ...

A new study reveals emerging applications for attaching very-fine-pitch parts using low-temp methods.

Electrically conductive adhesives (ECAs) have been touted for decades as a potential replacement for solder. Technology roadmaps by organizations ranging from IPC to the Surface Mount Council often listed ECAs as a “coming” technology, and scores of papers have been presented highlighting possible uses and likely end-products.

In early October, the international research firm IDTechEx released a new study called “Electrically Conductive Adhesives 2022-2032: Technologies, Markets, and Forecasts.” Matthew Dyson, Ph.D., a senior technology analyst at IDTechEx specializing in printed, organic and flexible electronics, spoke with Mike Buetow about the study’s findings.

To continue reading, please log in or register using the link in the upper right corner of the page.

Read more ...

Updates in silicon and electronics technology.

Ed.: This is a special feature courtesy of Binghamton University.

IBM announces 2nm GAA-FET technology. IBM announced its 2-nanometer CMOS technology, developed at its Albany research center. The development has technical firsts: the use of bulk Si wafers with bottom dielectric isolation under the nanosheet stack; reducing leakage and enabling 12-nnm gate lengths; a second-generation inner spacer dry process for precise gate control; FEOL EUV patterning to allow nanosheet widths from 15 to 70nm; and a novel multi-Vt scheme. This technology is expected to give a 45% performance boost or 75% power reduction, compared with the 7nm. (IEEC file #12324, Semiconductor Digest, 6/11/21)

11-ieee-figure-1

Light-based method creates 2-D polymer. Linköping University researchers developed a method that uses light to manufacture 2-D polymers that have the thickness of a single molecule and could create a path for the development of ultra-thin, functional 2-D materials with highly defined crystalline structures. Using an on-surface photo-polymerization process, they tested a way to manufacture a 0.5nm-thick, 2-D polymer consisting of several hundred thousand molecules identically linked. The two-step method takes advantage of the self-organizing properties of fluorinated anthracene triptycene molecules. Because the polymerization takes place in a vacuum, the material is protected from contamination. The 2-D polymer film is stable under atmospheric conditions. (IEEC file #12370, Photonics Spectra, 7/14/21)

To continue reading, please log in or register using the link in the upper right corner of the page.


A decade in, IPC-2581 Consortium members say the pursuit toward widespread adoption of the vendor-neutral standard was well worth the rigorous effort.

Few engineers working in electronics manufacturing today predate the first efforts to develop and implement an industry-wide standard for intelligent electronics data transfer.

As early CAD tools were introduced in the late 1960s and early 1970s, IPC launched a vendor-neutral effort to describe electronics design data from schematic through test.

To continue reading, please log in or register using the link in the upper right corner of the page.

Read more ...

Realizing advanced electronics with the world’s smallest packages.

Is it worthwhile to design printed circuit boards with the smallest component package available today: the 008004? And how do you do it correctly?

Several months ago, a hardware engineer in a high-tech company that is developing virtual reality headsets approached me. “These are special glasses that can integrate into game consoles in hundreds of millions of homes worldwide,” he said with excitement. “This is innovative technology that will enable a totally different viewing and gaming experience than what’s available at present.”

To continue reading, please log in or register using the link in the upper right corner of the page.


SAC 305 shows faster shear strength degradation than Innolot, while the surface finish has no effect.

When a solder joint is exposed to cyclic stresses, thermally activated diffusion in the bulk solder, metallization and initial intermetallic (IMC) may take place. The growth of the interfacial IMC helps relieve the residual stress induced in the solder joint, and the growth rate corresponds to the magnitude of stress induced.1 Solder joint strength also decreases during exposure to temperature variations. Therefore, shear testing is a useful method to assess solder joint strength degradation caused by thermal cycling.2

In part one3 of this series we showed the voiding, solder spread and thickness of the high-reliability Innolot alloy compared with SAC 305 alloy solder pastes using five different surface finishes. Part two discusses thermal cycling effects on the growth in IMC thickness and solder joint strength. This study included two commonly used solder alloys in paste form:

  1. SAC 305 (96.5%Sn, 3%Ag, 0.5%Cu) powder size distribution (PSD) type 4 with novel “CVP-390” paste flux
  2. Innolot (91.95%Sn, 3.8%Ag, 0.7%Cu, 3.0%Bi, 1.4%Sb, 0.15%Ni) PSD type 4 with the novel paste flux and five variations of surface finishes, including
    • Organic solderability preservative (OSP) (MacDermid Enthone Entek Plus HT) using two thickness levels
    • Immersion tin (Ormecon CSN)
    • Immersion silver (MacDermid Enthone Sterling)
    • Electroless nickel/immersion gold (ENIG) (MacDermid Enthone Affinity).

To continue reading, please log in or register using the link in the upper right corner of the page.
