DM3NW series MicroSD connector enables smaller consumer electronic designs by reducing volumetric space by up to 15%.

Push/push type connector is reportedly ideal for consumer electronic applications including digital cameras, digital video cameras, laptops, printers, smartphones, surveillance cameras, tablets and TVs. Is designed with card detection switch that indicates card presence and card guide to prevent incorrect card insertion. If inserted backward, upside down and/or at an angle, card guide stops without entering inside connector. Card guide protects contacts from damage during mating process; allows for easy removal if wrong type of card, like a micro SIM, is inserted. Once mated, card lock mechanism holds card in place. Card lock mechanism has retention force of 4N. Connector is 15.3mm x 13.4mm x 1.15mm. Has mating cycle rating of 10,000. Has operating temp. range of -30°C to +85°C, rated current of 0.5A and rated voltage of 10V.

Hirose DM3N Series image

Hirose Electric
hirose.com
