Kyocera AVX's SNA and SNL Series snap-in aluminum electrolytic capacitors are said to deliver high-reliability, high-voltage and high-CV performance over long lifetimes.

Are lead-free compatible and RoHS compliant, rated for temperatures extending from -25°C to +105°C, and are said to be ideal for use in commercial and industrial applications including frequency converters, solar inverters, power inverters, energy storage systems, and power supplies.

SNA series exhibit high ripple current capabilities, long lifetime performance and endurance of 5,000 hr. at 105°C. Are available with three rated voltages (250, 420, and 450VDC), 24 case sizes spanning 22mm x 25mm to 35mm x 50mm (D x L) and capacitance values extending from 82µF to 1,500µF ±20%.

SNL series exhibit endurance of 3,000 hr. at 105°C. Are available with eight rated voltages (160, 200, 250, 350, 400, 450, 500, and 550VDC), 36 case sizes spanning 22mm x 20mm to 35mm x 60mm (D x L), and capacitance values extending from 68µF to 2,200µF ±20%.

Kyocera AVX

kyocera-avx.com

Kyocera-SNA-SNL
